SHENGHE supplies UHMWPE fiber from 10D to 3000D, with different denier sizes and custom specifications available for a wide range of industrial applications. Selected high-strength grades are used in military and law enforcement protective equipment, including body armor, stab-resistant vests, ballistic inserts, helmets, protective shields and vehicle armor. UHMWPE fiber is also widely used in civilian products such as fishing lines, lifting and towing ropes, cut-resistant gloves, cooling textiles, luggage and bags, bite-resistant pet products, sports equipment and fiber-optic cable reinforcement. Material grades and specifications can be selected according to the strength, weight and processing requirements of each application.

Material

100% Ultra High Molecular Weight Polyethylene

Yarn Type

Continuous Multifilament

Denier

10D–3000D

Linear Density

33–3333.3 dtex

Filament Count

10F–960F

Tensile Modulus

200–2000 cN/dtex

Elongation at Break

≤4% for the referenced high-strength grades

Color

Natural White / Red /Blue / Custom Colors

Packaging

Roll+cardboard box / Customized Packaging

GET A QUOTE

Key Properties of UHMWPE Fiber

High Strength Without Heavy Yarn

Low Density

Good Abrasion Resistance

Cut Resistance

Chemical Resistance

What Is UHMWPE Fiber?

UHMWPE fiber is a high-strength polyethylene fiber made from ultra high molecular weight polyethylene. Unlike ordinary polyethylene yarn, UHMWPE fibers have highly oriented molecular chains that allow the material to carry substantial tensile loads at a low weight.

UHMWPE filament is commonly produced through gel spinning and subsequent drawing. This process aligns the molecular chains and gives the fiber its high strength and stiffness.

UHMWPE yarn is used where ordinary textile fibers may not provide enough strength for the required weight. It is especially useful in products that need high tensile performance without the added weight of heavier reinforcement materials.

The right grade still matters. Two UHMWPE fiber products with the same denier may have different breaking strengths, moduli and creep behavior.

Get a quote

UHMWPE Fiber– Technical Specifications

Specification	Medium Strength	Medium-High Strength	High Strength	Ultra-High Strength
Tenacity (cN/dtex)	10–20	20–30	30–40	40–50
Denier (D)	350–1600	1600	10–3000	800–1600
Filament Count (F)	120–240	480	10–960	480–960
Elongation at Break (%)	≤10	≤4	≤4	≤4
Tensile Modulus (cN/dtex)*	≥200	≥900	700–1200	1200–2000
Customization	Available	Available	Available	Available

*Reference specifications based on the supplied grade chart. Tensile modulus units and grade-specific availability should be confirmed before ordering. Custom specifications are available upon request.

UHMWPE Fiber vs. Other Industrial Fibers

Property	UHMWPE Fiber	Para-Aramid Fiber	LCP Fiber	Industrial Polyester (PET)	Industrial Nylon (PA)
Fiber Category	High-performance	High-performance	High-performance	Conventional / High-tenacity	Conventional / High-tenacity
Density (g/cm³)	≈0.97	≈1.44	≈1.40	≈1.38	≈1.14
Strength-to-Weight Ratio	Very high	High	High	Moderate	Moderate
Heat Resistance	Limited	High	Higher than UHMWPE	Moderate	Moderate
Moisture Absorption	Very low	Moderate	Very low	Low	Higher
Long-Term Creep	Important under sustained load	Generally low	Low	Load-dependent	Load-dependent
Breaking Elongation	Low	Low	Low	Moderate	Generally higher
Abrasion Resistance	Good	Construction-dependent	Good	Good	Good
Typical Uses	Lightweight ropes, nets, cut-resistant textiles	Heat-resistant reinforcement, protective textiles	Cables, ropes, tension members	Industrial fabrics, webbing, ropes	Ropes, industrial yarns, flexible textiles

Related UHMWPE Fiber Products

Para Aramid Fiber

Learn More

Para Aramid Fabric

Learn More

Hppe Fabric

Learn More

Hppe Gloves

Learn More

Applications of UHMWPE Fiber

High-Strength Ropes & Cables

UHMWPE fiber is used in braided ropes, industrial cords and high-strength lines where weight and tensile performance matter. Its low density helps keep the finished rope lighter, which can make handling and installation easier.

Cut-Resistant Gloves & Protective Textiles

UHMWPE yarn is widely used in yarn systems for cut-resistant gloves, sleeves and other protective textiles. Its strength and low weight make it useful in products where flexibility and wearability matter. UHMWPE fiber can also be combined with other yarns or reinforcement materials.

Fishing Lines & Nets

UHMWPE filament yarn is used in braided fishing lines, commercial fishing nets and aquaculture products. Low water absorption and a high strength-to-weight ratio make the material practical for marine use.

Outdoor & Sports Equipment

High tenacity UHMWPE yarn is used in lightweight cords and selected sports and outdoor products. It is often chosen where a low-weight, high-strength line is required. Finished-product performance depends on knots, splices, braiding, exposure conditions and other design factors.

Cut-Resistant Clothing & Equipment

UHMWPE fiber is commonly used in cut-resistant gloves, sleeves, protective clothing and other safety textiles. Its high tensile strength and low weight make it useful for protective products that need to remain flexible and comfortable during daily work. UHMWPE yarn can be knitted or combined with other fibers, such as nylon, glass fiber or stainless steel, to produce different protective yarn constructions.

Ballistic & Protective Equipment

Selected grades of UHMWPE fiber are used to manufacture ballistic UD composites for body armor, helmets, ballistic plates, protective shields and vehicle armor. The fiber s high strength-to-weight ratio helps reduce the weight of protective systems, which is important for equipment that needs to be worn, carried or installed on vehicles.

Why Work with SHENGHE for UHMWPE Fiber?

Regular Sizes and Custom Requirements

SHENGHE supplies UHMWPE fiber in 50D - 3000D, with custom specifications available for review. You can order against an existing yarn specification or discuss a different strength grade for a new product.

Specification-Based Communication

If you are comparing UHMWPE yarn suppliers, you need more than a material description. Tell us the strength, modulus, elongation or processing requirements you are working with. We can review the requested values and discuss suitable specifications.

Support for Industrial Processing

UHMWPE filament yarn is used in different manufacturing processes, and each process places different demands on the yarn. Whether your project involves weaving, braiding or other textile production, share your processing details early so that yarn size and package requirements can be considered before the order is confirmed.

FAQ About UHMWPE Fiber

Is UHMWPE fiber the same as Dyneema?

UHMWPE fiber is a material category. Dyneema is a commercial brand of UHMWPE-based high-performance materials.
Different manufacturers offer different grades, so the technical specifications should be compared rather than assuming the products are identical.

What denier sizes are available?

SHENGHE offers UHMWPE yarns in specifications ranging from 10D - 3000D.
Other denier sizes can be reviewed for custom orders. Share your target specification and expected quantity.

Can you customize the strength of UHMWPE filament yarn?

Yes. We can review different strength requirements and available grades. Please provide your target tenacity or minimum breaking load, along with the required denier. Actual achievable values need to be confirmed for the selected specification.

Is UHMWPE fiber waterproof?

UHMWPE fiber has very low moisture absorption and does not readily absorb water. That does not automatically make a fabric waterproof. Waterproof performance depends on the fabric construction, coating, membrane and seams.

Can UHMWPE fiber withstand high temperatures?

UHMWPE fiber has limited heat resistance compared with aramid and other high-temperature fibers.
It should not be selected for continuous high-temperature service based only on its melting point. Operating temperature, load and exposure time must be considered.

Can you supply UHMWPE fiber for ballistic applications?

Specialized UHMWPE fiber grades are used in ballistic composites.

Suitability for a particular protective application must be confirmed against the required material specification and finished-product testing. Ordinary industrial yarn should not be assumed to meet ballistic requirements.

What information is needed for a quotation?

Please send your denier, target strength, color, quantity and end use.
If you have an existing UHMWPE yarn datasheet or a sample specification, that is also useful. We can check the requested grade and available custom options before quoting.
